Hacking linux kernel to change shebang implementation

Linux Hacking

Introduction

So a past few days, I was watching this video. And it went in depth about how the shebang works in various operating systems.

Shebang

If you are not familiar on what the shebang is. It’s the first line on a executable script. And this tells the kernel which interpreter/executable to run.

For example, imagine the following script that prints every argument to the console.

#!/bin/sh

printf 'arg[0] = %s\n' "$0"
index=1
for arg in "$@"
do
    printf 'arg[%d] = %s\n' "$index" "$arg"
    index=$((index + 1))
done

chmod u+x script.sh # Add execution permissions for owner user
./script.sh # Execute the shell script

So the first line on a script file that starts with #! is called the shebang. And the contents of the shebang is /bin/sh so that is going to be the interpreter to call that script.

What happens under the hood depends on the kernel implementation. But on linux ./script.sh gets replaced with /bin/sh ./script.sh. So the filepath of the executable itself gets appended at the end of the shebang interpreter.

Python shebang

What this implies is that in the shebang you can put any interpreter/executable. And as long as that interpreter ignores the shebang as being source code, it will execute that script.

For example, imagine you have this python script:

print('Hello world!')

In order to execute, you would probably call it like this:

$ python main.py
Hello world!

But the shebang allow you to turn this python source code into a executable script:

#!/usr/bin/env python
print('Hello world')

/usr/bin/env is a executable that exists in most posix compliant OS, that will find the python executable in the first directory defined by your PATH environment variable.

And by making it executable, you don’t need to invoke python on the command line.

$ chmod u+x ./main.py
$ ./main.py # The kernel will replace this process context with: /usr/bin/env python ./main.py
Hello world!

C program to print argv

And to better visualize what arguments are passed. Let’s write a simple c program that prints every argument in argv (being the list of arguments of the process).

// printargs.c

#include <stdio.h>

int main(int argc, char **argv)
{
    for (int i = 0; i < argc; ++i) {
        printf("arg[%d] = %s\n", i, argv[i]);
    }

    return 0;
}

$ make printargs # cc -o printargs printargs.c
$ ./printargs
arg[0] = ./printargs
$ ./printargs 1 2 3
arg[0] = ./printargs
arg[1] = 1
arg[2] = 2
arg[3] = 3
$ ./printargs arg{1..10}
arg[0] = ./printargs
arg[1] = arg1
arg[2] = arg2
arg[3] = arg3
arg[4] = arg4
arg[5] = arg5
arg[6] = arg6
arg[7] = arg7
arg[8] = arg8
arg[9] = arg9
arg[10] = arg10
$ ./printargs 'hello world' foo bar
arg[0] = ./printargs
arg[1] = hello world
arg[2] = foo
arg[3] = bar

Now let’s make a executable shell script that calls printargs:

#!./printargs

$ chmod u+x ./shebang.sh
$ ./shebang.sh
arg[0] = ./printargs
arg[1] = ./shebang.sh

When executing the ./shebang.sh shell script the kernel read the first line of the source code and it detected a shebang that starts with #!. And then replaced ./shebang.sh with ./printargs and then appended the filename of the script itself ./shebang.sh. ./shebang.sh = ./printargs ./shebang.sh.

Now that you understand the concept of the shebang, we will do slight modifications to the shebang, so to uncover how the implementation of the shebang works on the linux kernel. Because that is the intent behind this post. I would like to understand how the shebang works under the hood and modify it to fit our needs.

Change the shebang.sh like this:

1c1
< #!./printargs
---
> #!./printargs arg1

#!./printargs arg1

$ ./shebang.sh
arg[0] = ./printargs
arg[1] = arg1
arg[2] = ./shebang.sh

We added an argument to the shebang, and the output of the script is expected. arg1 is the second argument before the appended filepath of the script ./shebang.sh.

But now let’s try and add another argument

#!./printargs arg1 arg2

$ ./shebang.sh
arg[0] = ./printargs
arg[1] = arg1 arg2
arg[2] = ./shebang.sh

If you notice carefully the arg2 argument of the shebang was not treated as a different argument when passed to ./printargs.

We might expect:

arg[1] = arg1
arg[2] = arg2

But this is not what happens, even tough arguments are space separated, the implementation in the linux kernel treats everything between the interpreter and the new line as a single argument, that’s why arg1 arg2 is passed as a single argument to printargs. This would be equivalent to:

$ ./printargs 'arg1 arg2'
arg[0] = ./printargs
arg[1] = arg1 arg2

Now on the next chapter, we will hack the linux kernel to understand the implementation of the shebang and we will modify it so that every argument space separated to be passed separately to the interpreter.

Kernel hacking

To make sure, that everyone following the post gets the same version of the linux kernel. I have prepared a git repo with a version pinned down so you can reproduce on your own machine.

There is a flake.nix with the necessary dependencies and tools to follow this tutorial, so you can activate the environment with nix develop.

Cloning and compiling linux kernel

git clone --depth=1 --recursive https://github.com/shelltux/linux-debug
cd linux-debug
make defconfig
make menuconfig
# [ ] - turn off
# [x] - turn on

# [ ] Processor type and features >>> Randomize the address of the kernel image (KASLR) -> This is a security feature, we will disable it so we can debug it with gdb
# [ ] Virtualization -> No need for virtualization
# [ ] Enable loadable module support -> No need for loading modules at runtime
# [ ] Networking support -> No need to reach over the network
# [x] Kernel hacking >>> Compile-time checks and compiler options >>> Debug information >>> Rely on the toolchain's implicit default DWARF version
# [x] Kernel hacking >>> Compile-time checks and compiler options >>> Provide GDB scripts for kernel debugging
make --jobs=$(nproc) # It will take awhile

Compiling my own utilities to replace GNU coreutils

In ./rootfs/src directory contains my own simple reimplementations of some GNU coreutils, so I can interact with the system via text/shell. I made this so I didn’t need to pull the source code of coreutils to this repo and it is necessary to have static linked executables because dynamic linking is not set up.

Feel free to read the source code, the most important files are:

init.c -> first program to be called
shell.c -> simple shell
printargs.c -> prints arguments in argv

# This command will compile and prepare rootfs.cpio.gz that contains the root
# filesystem for the linux kernel
make --directory=rootfs --jobs=$(nproc) # make -C rootfs -j4

Running kernel

I prepared a shell script to launch qemu with the necessary flags.

./startvm.sh

Getting familiar with the tools

After starting using startvm.sh script, you can launch any executable in /usr/local/bin:

# You can use ls to list contents of directory
$ ls -lc /usr/local/bin
# You can use tee to write to a file, and stop writting to the file by closing
# stdin (Ctrl+d). -q just doesn't redirect to stdout so you see duplicate lines.
$ tee -q /tmp/shebang.sh
#!/usr/local/bin/printargs
(ctrl+d)
# use cat to see the content of a file
$ cat /tmp/shebang.sh
#!/usr/local/bin/printargs
# You can use chmod to change permissions the mode needs to be in octal mode
$ chmod 755 /tmp/shebang.sh # rwxr-xr-x
# Execute the script
/tmp/shebang.sh
$ tee -q /tmp/shebang.sh
#!/usr/local/bin/printargs foo bar baz
(ctrl+d)
$ /tmp/shebang.sh

Notice that foo bar baz is passed as a single argument.

linux-debug-tools

Debugging the kernel

Now let’s move to debugging the linux kernel. We will do this by using gdb to open a debugging remote session. qemu is already setup with a gdb server if you launch the vm by ./startvm.sh.

The -s flag when passed to qemu will open a gdb server session at 1234 port.

I have tracked down where the shebang implementation is by ripgrepping "#!":

cd linux
rg '"#!"'

And I have found load_script function inside linux/fs/binfmt_script.c, so will be setting a breakpoint inside this function.

On 2 terminal panes:

run linux kernel

./startvm.sh

Open gdb session

(gdb) break load_script
(gdb) target remote :1234

linux-gdb

Take your time to understand why everything after the interpreter is considered a single argument.

Modifying the kernel

I have wrote a patch that modifies the shebang implementation to separate arguments by whitespace.

diff --git i/fs/binfmt_script.c w/fs/binfmt_script.c
index 637daf6e4..ba71b8e35 100644
--- i/fs/binfmt_script.c
+++ w/fs/binfmt_script.c
@@ -30,6 +30,42 @@ static inline const char *next_terminator(const char *first, const char *last)
 			return first;
 	return NULL;
 }
+static inline char *strtok_r(char *text, const char *delimitors,
+			     char **save_this)
+{
+	if (save_this == NULL) {
+		return NULL;
+	}
+
+	if (text != NULL) {
+		/* New text. */
+		for (int i = 0; text[i] != '\0'; ++i) {
+			for (char *d = (char *)delimitors; *d != '\0'; d++) {
+				if (text[i] == *d) {
+					text[i] = '\0';
+					*save_this = &text[i + 1];
+					return text;
+				}
+			}
+		}
+	} else if ((save_this != NULL) && (*save_this != NULL)) {
+		/* Old text. */
+		char *start = *save_this;
+		for (int i = 0; (*save_this)[i] != '\0'; ++i) {
+			for (char *d = (char *)delimitors; *d != '\0'; ++d) {
+				if ((*save_this)[i] == *d) {
+					(*save_this)[i] = '\0';
+					*save_this = &((*save_this)[i + 1]);
+					return start;
+				}
+			}
+		}
+		*save_this = NULL;
+		save_this = NULL;
+		return start;
+	}
+	return NULL;
+}

 static int load_script(struct linux_binprm *bprm)
 {
@@ -113,10 +149,40 @@ static int load_script(struct linux_binprm *bprm)
 	*((char *)i_end) = '\0';
 	if (i_arg) {
 		*((char *)i_sep) = '\0';
+
+#define SHEBANG_SEPARATE_ARGS 1
+
+#if SHEBANG_SEPARATE_ARGS
+
+#define MAX_ARGS 64
+
+		char *save_ptr = NULL;
+		char *args[MAX_ARGS] = { 0 };
+		size_t argsSize = 0;
+
+		for (char *arg = strtok_r((char *)i_arg, " ", &save_ptr);
+		     arg != NULL; arg = strtok_r(NULL, " ", &save_ptr)) {
+			args[argsSize++] = arg;
+
+			if (argsSize >= MAX_ARGS)
+				break;
+		}
+
+		/*
+		 * Copy args to argv in reverse order
+		 */
+		for (char **arg = &args[argsSize - 1]; arg >= args; arg--) {
+			retval = copy_string_kernel(*arg, bprm);
+			if (retval < 0)
+				return retval;
+			bprm->argc++;
+		}
+#else
 		retval = copy_string_kernel(i_arg, bprm);
 		if (retval < 0)
 			return retval;
 		bprm->argc++;
+#endif
 	}
 	retval = copy_string_kernel(i_name, bprm);
 	if (retval)

Apply the patch

# Apply the patch
cd linux
git apply < ../binfmt_script.patch
make -j4 # Recompile

post-patch
